Pressure Seal Bonnet Globe Valve

Pressure Seal Bonnet Globe Valve

BS1873 Cast Steel Industrial Globe Valve, Pressure Seal Bonnet (PSB) Design, High Pressure Ansi Class 1500Lb and 2500Lb, Rising Stem, Outside Screw and Yoke (OS&Y), Carbon Steel and Stainless Steel Metal Seated Plug Disc Globe Valves.

Specification For Pressure Seal Bonnet Globe Valve 1500LBS - 2500LBS :
1. Design & Manufacture: ANSI B16.34, BS 1873
2. OS&Y Construction, Bolted Bonnet, Pressure Sealing Bonnet
3. Size Range of Globe Valve: 2" to 12" / Dn50 - Dn300
4. Pressure Ratings: ANSI 1500LB, 2500LB
5. End Connections: Flanged, Butt Weld
6. Materials Available in: WCB, LCB, CF8, CF8M, CF3, CF3M, WC6, WC9, C5, C12, Duplex Stainless Steel or Equivalent
7. Various Trim Materials are Available to Suit Service Conditions
8. Actuator: Handwheel, Gearbox

9. NACE MR 0175 on Request
