Basket Strainer Din PN16 - PN25 (Fabricated Body)

  • Pressure rating: PN10, PN16, PN25, PN40
  • Body material: carbon steel, alloy steel, stainless steel.
  • Screen: Stainless steel (304SS, 316SS, 304LSS, 316LSS)
  • Mesh size: 20mesh, 40mesh, 60mesh, 80mesh, 100mesh, 200mesh, 400mesh etc
  • Din Basket Strainer Fabricated Type , Bucket Strainer Welded Body , DIN PN16 , PN25 , Flanged , BW Ends , Bolted Cover , Carbon Steel , Stainless Steel , Simplex Basket Strainers Supplier And Manufacturer
    Inquiry Send Email

    Description

    Basket Strainer Din PN16 - PN25 (Fabricated Body)

    Basket Strainers Supplier, Exporter, Offers Industrial, Flanged, Bw Ends, Carbon steel (CS), Stainless Steel (SS), Duplex Steel (DSS), Iron, Simplex Basket Strainers; Cast, Welded, Fabricated Body Basket Strainers Sizes From 2Inch to 24Inch, Pressure Rating to Ansi Class 150Lbs, 300Lbs, 600Lbs, And Din to Pn10, Pn16, Pn25;
    All BaskeT type strainer Baskets (Screens) and Mesh Materials In a Wide Range: Stainless Steel (304SS, 316SS), Duplex Stainless Steel (DSS, 2205), Monel etc.
    The Perforated Screens & Mesh Hole Size as Required.
    Basket strainer (simplex basket strainer, Duplex Basket Strainer) is a kind of equipment that it remove small impurities from liquid, gases and pipe system with the use of a perforated screen, protect the normal operation to the pump, instruments, and other equipment.

    BASKET STRAINER STANDARDS:

    •  Sizes: DN50 to DN900
    •  Pressure rating: PN10, PN16, PN25, PN40
    •  Suitable medium: Water, gas, oil, steam etc.
    •  Body material: carbon steel, alloy steel, stainless steel.
    •  Screen: Stainless steel (304SS, 316SS, 304LSS, 316LSS)
    •  Mesh size: 20mesh, 40mesh, 60mesh, 80mesh, 100mesh, 200mesh, 400mesh etc
    •  End connection: BW, RF, RTJ
    •  Others on request.
